page 3 - 6

MHP12/34J – 11447A

3. Specifications

Oil tank

cover

Outrigger cylinder

Hand

brake

Upper

cylinder

Lower cylinder

Jib Cylinder

❑

Left side view of machine

Serial number

plate

❑

Serial number location, chassis
