Chapter 3. Specifications
The Snor kel EPV16J is a boom sup ported el e vat ing work plat form built to con form to all ap pli ca ble OSHA,
ANSI or CSA stan dards as pre vi ously out lined.
OSHA Para graph 1910.67 Ti tle 29, C.F.R., Ve hi cle-Mounted El e vating and Ro tating Work Plat forms - La -
bour.
OSHA Para graph 1926.556 Ti tle 29, C.F.R., Ae rial Lifts - Con struc tion.
Aus tra lian Stan dard AS1418-10 1996 El e vating Work Plat forms.
NOTE:
For further details regarding lubricants, maintenance schedules and service please refer to the
Maintenance and Repair Parts Manual for this machine.
■ General Specifications
■ Recommended Hydraulic Oil
Shell Tellus 32 or Castrol AWS 32 or similar
EPV16J – 11089A
page 3 - 1
SPECIFICATIONS
EPV16J
Nominal working height
15.8m
51’ 10”
Maximum height to basket floor
13.8m
45’ 3”
Maximum outreach
7.0m
23’
Maximum outreach height
? 6.90m
22’ 6”
Nominal Maximum width of base
2m
6’ 5”
Safe working load (unrestricted)
200kg
440lbs
Standard colour
Charcoal base / white booms
Platform size
1200 x 760 x 1100mm
Aluminum
4’ x 2’ 6” x 3’ 7”
Aluminum
Nominal Travelling height
2.8m
9’ 2”
Nominal Overall length
6.75m
22’ 6”
Turntable rotation
360
o
continuous
Insulation rating (Optional)
5KV
Nominal weight
1700kg
3746lb
