S PECIFICATIONS
Specifications are subject to change without notice
Meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999
ITEM XRT27 XRT33
Platform Size (Outside)
Standard 58 in. x 90.5 in. [1,47 m x 2,34 m] 58 in. x 90.5 in. [1,47 m x 2,34 m]
Slide Out Deck Extended 58 in. x 131 in. [1,47 m x 2,62 m] 58 in. x 131 in. [1,47 m x 2,62 m]
Max. Platform Capacity
Standard 1,250 lbs. [567 kg] 1,000 lbs. [454 kg]
on Extension 250 lbs. [113 kg] 250 lbs. [113 kg]
Max. No. of occupants
Standard 4 people 3 people
on Extension 1 person 1 person
Height
Working Height 33 ft. [10,1 m] 39 ft. [12 m]
Max. Platform Height 27 ft. [8,2 m] 33 ft. [10,1 m]
Max. Drive Height 27 ft. [8,2 m] 33 ft. [10,1 m]
Dimensions
Weight, Standard 7,000 lbs. [3175 kg] 8,167 lbs. [3704 kg]
Overall Width 69in. [1,75 m] 69 in. [1,75 m]
Overall Height (Rails Up) 98.5 [2,5 m] 105 in. [2,7 m]
Overall Height (Rails Folded) 69.5 in. [1,8 m] 76 in. [1,9 m]
Overall Length, Standard 106 in. [2,72 m] 106 in. [2,72 m]
Drivable Height 27 ft. [8,2 m] 33 ft. [11,1 m]
Drive Speed
Platform Lowered 0 to 6.4 mph [0 to 4,0 km/h] 0 to 6.4 mph [0 to 4,0 km/h]
Platform Raised 0 to 0.45 mph [0 to 0,73 km/h] 0 to 0.45 mph [0 to 0,73 km/h]
System Voltage 12 Volt DC 12 Volt DC
Fuel Tank Capacity 16.25 US Gallons [74 l] 16.25 US Gallons [74 l]
Hydraulic Tank Capacity 16.25 US Gallons [74 l] 16.25 US Gallons [74 l]
Maximum Hydraulic System Pressure 3200 psi [220,7 bar] 3200 psi [220,7 bar]
Hydraulic Fluid
Normal use: Above 32° F [0° C] ISO #46 ISO #46
Low Temp. use: Below 32° F [0° C] ISO #32 ISO #32
Below 0° F [-17° C] ISO #15 ISO #15
Lift System One Single Stage Lift Cylinder Two Single Stage Lift Cylinders
Lift Speed Raise, 35 sec./Lower, 31 sec. Raise, 30 sec./Lower, 31 sec.
Power Source Diesel - Kubota D905E Diesel - Kubota D905E
Dual Fuel - Kubota WG750
Gasoline/Propane
Dual Fuel - Kubota WG750
Gasoline/Propane
Drive Control - Proportional Four Hyd. Wheel Motors Four Hyd. Wheel Motors
Air Filled Tires
(except foam filled tires)
26 X 12-10 ply, 65 psi [4,5 bar] 26 X 12-10 ply, 65 psi [4,5 bar]
Parking Brakes
Spring Applied, Hydraulic Release,
Multiple Disc
Spring Applied, Hydraulic Release,
Multiple Disc
Turning Radius (inside) 68 in. [1,7 m] 68 in. [1,7 m]
Maximum Gradeability 40% [21,9°] 35% [19,2°]
Ground Clearance 7.6 in [194 mm] 7.6 in [194 mm]
Wheel Base 78 3/8 in. [2 m] 78 3/8 in. [2 m]
Guardrails 44 in. [1,1 m] high, Fold Down 44 in. [1,1 m] high, Fold Down
Toeboard 6 in. [152 mm] High 6 in. [152 mm] High
