Page 10 XRT Work Platform
Figure 8: Transporting the Work Platform
B Y C RANE
1. Secure straps to Lifting Lugs
only.
B Y T RUCK
1. Maneuver the work platform
into transport position and
chock the wheels. The plat-
form must be in the fully low-
ered position for transport.
2. Secure the work platform to
the transport vehicle with
chains or straps of adequate
load capacity attached to the
front and rear Tie Downs on
both sides of the chassis.
T RANSPORTING W ORK P LATFORM
Front Tie Downs
Lifting Lugs
Rear Tie Downs / Lifting Lugs
C A U T I O N ! !
Overtightening of chains or straps through tie down lugs may result in
damage to work platform.
