12. OPTIONS
12 - 3 P/N 569300
T
SPARK ARRESTOR
The spark arrestor prevents incandescent
carbon particles from coming out the tail pipe.
Baffles in the spark arrestor slow the flow of
particles through the exhaust system. The
additional time spent in the exhaust system lets
the carbon completely burn before it comes out
the tail pipe.
T
LANYARD ANCHOR POINTS
There are four anchors on the floor of the
platform, one at the front of the roll-out deck,
one at the back of the platform, and one on
each side of the platform.
NOTE: These anchors are not for lifting or
tying down the machine.
You should attach your fall protection to the
anchors if work rules require it.
T
AC GENERATOR
C A U TIO N
Do not use the ac generator unless the
hydraulic oil is over 70
°F (21°C). The output
voltage of the generator depends on the
temperature of the hydraulic oil. Temperature
below 70
°F (21°C) will cause dangerously low
output voltages that can burn out some kinds of
electrical equipment.
The hydraulically powered, 115 V ac generator
can be used anytime the SR engine is running
and the SR is completely stationary. Turning
the ac generator on stops all machine
movement.
Set the AC OUTLET SWITCH, on the platform-
control box, to on (--) and a total of 2 kW,
continuous duty, 120 V ac power is available
from the two electrical outlets under the
platform-control box or the electrical outlet on
the end of the generator housing.
NOTE: To energize the two platform
electrical outlets, the power cord from the
platform outlets must be plugged into the
receptacle on the generator.
