8. EMERGENCY OPERATION

8 - 3

P/N 569300

2. At the base-control panel set the
EMERGENCY STOP switch (2) to off, turn the
MAIN POWER switch (3) off and remove the key
(4).

3. Inside the hydraulic compartment, completely
open the free-wheeling valve (5) (turn
counterclockwise until knob stops).

D A N G ER

A runaway SR can cause death or serious
injury. At the next step the SR brakes will be
released. Do not proceed to the next step
unless the SR is on a level surface or the SR
is securely attached to another vehicle that
has the capacity to safely control the SR on a
grade.

C A U TIO N

The SR drive motors will be ruined if the SR is
pushed (or pulled) faster than 2 mph (3.2 km/hr).
Unless personnel safety considerations dictate
otherwise, do not push (or pull) faster than 2 mph
(3.2 km/hr).

4. At the rear wheels, use a 3/4” box-end wrench
to release both of the brakes by turning the cams
(6)(7) as shown. Manually push the SR to safety.

5. As soon as the SR is in a safe place, reset the

brakes by turning the cams (8)(9) as shown.

6. Close the free-wheeling valve (10).
