6. CONTROLS

6 - 1

P/N 569300

This chapter explains what each control does.
This chapter does not explain how to use the
controls to produce useful work, refer to the
“OPERATION” chapter for that, after you have
read this chapter.

For optional-equipment controls, see the
“OPTIONS” chapter. The only optional-
equipment controls discussed in this chapter are
the controls for: diesel engines, dual-fuel
engines, LP-only engines, and outriggers.

See the “EMERGENCY OPERATION” chapter
for the location of the emergency bleed down
control and for correct emergency bleed down
procedures.

The main operating functions of an SR can be
controlled from the base-control panel (1) or the
platform-control box (2).
