10. DAILY INSPECTION & MAINTENANCE
10 - 10
P/N 569300
31. Placards, decals, and Operator’s Manual
Look to see that all placards and decals are in place and legible. Replace any missing or illegible
placards or decals before placing the SR into service for the daily work shift.
PLACARDS AND DECALS INSPECTION CHART
NO PART # DESCRIPTION REQ
1 257806 Snorkel logo 10”(white/blk) 2
2 300698 Snorkel logo 10”(Orange/blk) 2
3 605726 Diesel fuel only (option) 1
4 451786 Lowering valve 1
5 451986 Danger - do not alter 1
6 302820 Caution no step 1
7 464416 Check engine oil 1
8 300694 ANSI standards 1
9 476706 Danger - explosive fumes 1
10 560262 Electrical schematic 12 volt 1
11 0151410 Danger - rotating engine parts 1
12 560241 Platform-control box 1
13 560272 Emergency stop 1
14 562426 Operating manual enclosed 1
15 562436 Operator’s checklist 1
16 562446 Parking brake 3
17 562456 Danger - safety prop 1
18 560239 Snorkel logo 28” (orange/blk) 2
19 604896 Gasoline only 1
20 0070420 Emergency bleed down 1
21 300700 Danger - shear/crush hazard 4
22 0073585 Made in USA 2
23 480658 Danger - tipover/elect. hazard 2
24 969249 Warning stripe 213”
25 969676 Serial number 1
26 0090493 Dual fuel instructions (option) 1
27 560240 Base-control panel 1
28 475596 Caution - cylinder disassembly 2
29 0070921 115 volt 20 amp (option) 1
30 560335 Danger - explo fume/lq (option) 2
31 0102006 Battery disconnect switch 1
32 0073298 Danger - foam filled tires 1
33 451776 Hydraulic fluid level 1
34 467036 Full tank 1
35 560261 Hydraulic schematic 1
36 476706 Danger - explo fumes 1
Additional placards and decals found on SR2584.
NO PART # DESCRIPTION REQ
37 560233 SLH 2584hd logo 2
38 560256 25’ platform capacity 2
39 438296 Safety tread 3
40 560285 Tire pressure 44 PSI (option) 4
41 0151959 Danger - tipover hazard (option) 1
42 564806 Outrigger operating instr. (option) 1
43 583776 Danger - pinch point (option) 4
Additional placards and decals found on SR3284.
NO PART # DESCRIPTION REQ
37 560236 SLH 3284hd logo 2
38 560257 32’ platform capacity 2
39 438296 Safety tread 4
40 560285 Tire pressure 44 PSI (option) 4
41 0191959 Danger - tipover hazard (option) 1
42 564806 Outrigger oper. instr. (option) 1
43 583776 Danger - pinch point (option) 4
Additional placards and decals found on SR4084.
NO PART # DESCRIPTION REQ
37 560237 SLH 4084hd logo 2
38 560258 40’ platform capacity 2
39 438296 Safety tread 5
40 560285 Tire pressure 44 PSI (option) 4
41 0151959 Danger - tipover hazard (option) 1
42 564806 Outrigger operating instr. 1
43 583776 Danger - Pinch point 4
44 562456 Danger - safety prop 1
