7. OPERATION
7 - 9 P/N 569300
D A N G ER
The distribution of the RATED WORK LOAD
changes when the extendible platform is
extended. Read the decal on the toe board at
the front of the platform or at the entrance to
the platform for safe weight distribution.
2. Pull up and hold the lock pin (2) while you
push or pull the rails (3) just far enough to get
the lock pin (2) past the lock ramp (4).
3. Push or pull the rails (5) vigorously until the
extendible platform moves to the second
position.
4. The lock pin (6) should lock into the second
lock ramp (7).
7 - 9 (7 - 10 blank)
