page 7 - 10 Rev A SR3370 & SR2770 – 13184A
7. Daily Inspection and Maintenance
No Part No Description Req
1 1843 Decal - Warning, N.Z. only 1
9428 Decal - Electrical hazard,
Australia only 1
2 9208 Decal - Water 1
3 96924-9 D e c a l - W a r n i n g s t r i p e s
yellow/black 4m
4 0070901E Decal - Serial number 1
5 9751 Decal - N.Z. made 1
6 12671 Decal - X33RT
2
11345-1 Decal - X27RT
2
7 12699 Decal - Rated load, X33RT
1
11346-1 Decal - Rated load, X27RT
1
8 0073298 Decal - Foam tyres 1
9 451986 Decal - Interlocks 2
10 476706 Decal - Explosive fumes 2
11 12574 Decal - Danger with alarm 1
12 569295 Decal - Snorkel logo 5
13 560240 Decal - Lower control box 1
14 12689 Decal - Upper control box 1
15 560272 Decal - Emergency stop upper
box 1
16 605726 Decal - Diesel fuel 1
17 12753 Decal - Emergency bleed
down 1
18 12814 Decal - Hydraulic fluid 1
19 58365-6 Decal - Safety prop 1
20 9223-3 Decal - Chevron 4
21 300699 Decal - Operators checklist 1
22 0323897 Decal - Must not operate 1
23 621486 Decal - Forklift 4
24 302950 Decal - Hydraulic oil level 1
No Part No Description Req
25 300700 Decal - Shearing hazard 1
26 12816 Decal - Emergency operation,
e m e r g e n c y l o w e r i n g &
emergency pushing 1
27 0083427 Decal - Lifting/tie down 4
28 12815-4 Decal - Hydraulic circuit, RT
1
29 12815-2 Decal - Electrical circuit, RT
1
30 562426 Decal - Operators manual
enclosed 1
31 0372061 Decal - Torque wheel nuts 4
32 13182 Decal - www.snorkellift.com 2
■ Placards and Decals
Look to see that all plac ards and de cals are in place and leg i ble. Re place any miss ing or il leg i ble plac ards
or de cals be fore plac ing the
RT into ser vice for the daily work shift.
De cal and plac ard kits for the RT are avail able from Snor kel deal ers.
❑ Standard placards and decals
● See page 7 - 11 for the following items:
