Safety, Rear end of rt, X33rt x27rt – Snorkel X33BE-sn10131+V-1 User Manual
Page 19
page 1 - 8
Rev A
SR3370 & SR2770 – 13184A
1. Safety
REAR END OF
RT
X27RT PLATFORM RATINGS
UNIFORMLY DISTRIBUTED
RATED NUMBER OF OCCUPANTS: 2 PERSONS
12699
450kg
RATED WORK LOAD
RATED WORK LOAD
MAIN
DECK
EXTENSION
DECK
MAIN
DECK
990lb
120kg
264lb
330kg
726lb
EXTENSION DECK RETRACTED
EXTENSION DECK EXTENDED
X27RT PLATFORM RATINGS
UNIFORMLY DISTRIBUTED
RATED NUMBER OF OCCUPANTS: 5 PERSONS
11346-1
580kg
RATED WORK LOAD
RATED WORK LOAD
MAIN
DECK
EXTENSION
DECK
MAIN
DECK
1280lb
120kg
264lb
460kg
1015lb
EXTENSION DECK RETRACTED
EXTENSION DECK EXTENDED
X33RT
X27RT
