R OUTINE S ERVICE
Use the following table as a guide for routine mainte-
nance. Inspection and maintenance shall be per-
formed by personnel who are trained and familiar
with mechanical and electrical procedures. Refer
to the Service Manual for complete service instruc-
tions.
Please copy this page and use the Routine Service
Table as a checklist when inspecting a machine for
service.
R OUTINE S ERVICE T ABLE K EY
Interval
Daily=each shift or every day or every 8 hours
50h/30d=every 50 hours or 30 days
125h/3m=every 125 hours or 3 months
250h/6m=every 250 hours or 6 months
1000h/2y=every 1000 hours or 2 years
Y=Yes/Acceptable
N=No/Not Acceptable
R=Repaired/Acceptable
Preventative Maintenance Report
Date: _______________________________________
Owner:______________________________________
Model No: ___________________________________
Serial No:____________________________________
Serviced By: _________________________________
Service Interval:_______________________________
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
Batteries
Check electrolyte level 6m
Clean exterior & terminals 3m
Check specific gravity 30d
Check battery cable condition Daily
Engine Oil
and Filter
Check level and condition Daily
Check for leaks Daily
Change oil filter 100h
Engine Fuel
System
Check fuel level Daily
Check for leaks Daily
Replace fuel filter 6m
Check air cleaner Daily
Engine
Coolant
Check coolant level (with engine cold) Daily
Replace coolant 3m
Hydraulic
Oil
Check oil level Daily
Change filter 6m
Drain and replace oil 2y
Hydraulic
System
Check for leaks Daily
Check hose connections 30d
Check hoses for exterior wear 30d
Emergency
Hydraulic
System
Operate the emergency lowering valve and
check for serviceability Daily
Controller Check switch operation Daily
Control
Cable
Check the exterior of the cable for pinching,
binding or wear Daily
Platform
Deck and
Rails
Check fasteners for proper torque Daily
Check welds for cracks Daily
Check condition of operators manual Daily
Check condition of deck Daily
Tires
Check for damage Daily
Check air pressure (50psi-26x12.00-12NHS) Daily
Check lug nuts (torque to 90 ft. lbs.) 30d
Hydraulic
Pump
Wipe clean 30d
Check for leaks at mating surfaces 30d
Check for hose fitting leaks Daily
Check mounting bolts for proper torque 30d
Hydraulic
Drive
System
Check hydraulic drive motor operation Daily
Check hoses, fittings, and valve block for leaks Daily
Steering
System
Check hardware & fittings for proper torque 6m
Check linkage for wear areas 30d
Check for missing/loose retainers Daily
Check steering cylinder for leaks 30d
Elevating
Assembly
Inspect for structural cracks Daily
Check pivot points for wear 30d
Check pivot pin retaining bolts for proper torque 30d
Check members for deformation Daily
Chassis
Check hoses for pinch or rubbing points Daily
Check component mounting for proper torque 6m
Check swing bearing bolt (torque to 190 ft/lbs) 6m
Check welds for cracks Daily
Lift
Cylinder
Check the cylinder rods for wear 30d
Check pivot pin pivot bolts for proper torque 30d
Check seals for leaks 30d
Inspect pivot points for wear 30d
Check fittings for proper torque 30d
Axle
Cylinder
Check the cylinder rod for wear 30d
Check mounting pin pivot bolts for proper
torque 30d
Check seals for leaks 30d
Check fittings for proper torque 30d
Inspect pivot points for wear 30d
Entire Unit
Check for and repair collision damage Daily
Check fasteners for proper torque 3m
Check for corrosion-remove and repaint 6m
Lubricate 30d
Labels
Check for peeling, missing, or unreadable labels
& replace Daily
COMPONENT INSPECTION OR SERVICES INTERVAL Y N R
