Smittybilt DSx-x Defender Series Rack Mount User Manual

Page 2

WWW.SMITTYBILT.COM

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 West Artesia Blvd, Compton, CA 90220

Installation Instructions

Defender Series Rack Mount

Part #DS1-6, DS1-8, DS3-6, DS3-8,

DS4-4, DS4-6, DS4-8, DS9-4, DS9-6,

DS10-6, DS10-8, DS16-6, DS17-6

Part# DS4-8

Parts Included Qty

Bracket (DS4) 8

5/16” Lock Washer 16

Hardware Pack (DS4-8-HP)

5/16” Nut 16

5/16” x ¾” Bolt 16

5/16” Flat Washer 32

Part# DS9-4

Parts Included Qty

Bracket (DS9) 4

5/16” Lock Washer 8

Hardware Pack (DS9-4-HP)

5/16” Nut 8

5/16” x ¾” Bolt 8

5/16” Flat Washer 16

Part# DS9-6

Parts Included Qty

Bracket (DS9) 6

5/16” Lock Washer 12

Hardware Pack (DS9-6-HP)

5/16” Nut 12

5/16” x ¾” Bolt 12

5/16” Flat Washer 24

Part# DS10-6

Parts Included Qty

Bracket (DS10) 6

5/16” Lock Washer 12

Hardware Pack (DS10-6-HP)

5/16” Nut 12

5/16” x ¾” Bolt 12

5/16” Flat Washer 24

Part# DS10-8

Parts Included Qty

Bracket (DS10) 8

5/16” Lock Washer 16

Hardware Pack (DS2-4-HP)

5/16” Nut 16

5/16” x ¾” Bolt 16

5/16” Flat Washer 32

Part# DS16-6

Parts Included Qty

Bracket (DS16) 6

5/16” Lock Washer 12

Hardware Pack (DS16-6-HP)

5/16” Nut 12

5/16” x ¾” Bolt 12

5/16” Flat Washer 24
