Installation Instructions
Extended Top
(Part # 945xx JK 4-Door)
(Part # 941xx JK 2-Door)
Step 1: Remove your hardtop or lower your soft top down (if equipped).
Step 2: Lay your top on its top on a clean surface. Remove the knobs and latch bracket from
your header and then slide header into the front of the top.
Connect the snaps on the top to the ones on the header. (Fig A, B)
Step 3: Lay the header on top of the windshield frame and spread top back over vehicle.
(Fig C)
(Fig A) (Fig B)
(Fig C) (Fig D)
Note: Please read instructions thoroughly before installing this product. A windshield
header is required to install this. (Smittybilt part # 90105)
