Installation Instructions
Sure-Step (Part # JN49-S4x)
2007 Jeep Unlimited (4 Door)
Step 4: Attach the front and center brackets using the supplied 10mm hardware. Use one bolt, one flat
washer and one lock washer for each bracket. (Fig F) Do not tighten completely at this time.
(Fig F) (Fig G)
Step 5: Line the rear bracket up with the hole in the body and attach using the supplied 8x35mm hardware.
(Fig G)
Step 6: Attach the front of the brackets to the existing holes in the pinch-weld area on the body by using
the supplied 6 mm hardware. (Fig H, I ) Do not tighten completely at this time.
(Fig H) (Fig I)
