Installation Instructions
Sure Steps (Part # JN420-4S)
1984-2001 Jeep Cherokee XJ 4 Door
WWW.SMITTYBILT.COM
QTY PART # DESCRIPTION
1
JN420-S4L Sure-Step, left side
1 JN420-S4R Sure-Step, right side
1 601018 hardware kit
1 720009 warranty statement
NOTE:
Please read this information before installing. Check components received with components listed
above. DRILLING IS REQUIRED for installation of these Sure-Step side bars. To obtain correct
installation we recommend you to follow these step by step installation instructions carefully. Please take care
when installing this product to protect the finish and your investment.
Step One: Locate hardware marked 601018. Check contents of 601018 with the hardware listed below.
QTY PART # DESCRIPTION
4
901001 3/8-16 x 1 indented hex washer slotted type F bolts, zinc plated
12 901030 3/8-16 x 1 1/4 hex cap screws, zinc plated GR5
6 901014 3/8-16 hex nuts, zinc plated
12 901015 3/8 flat washers, zinc plated
12 901016 3/8 split lock washers, zinc plated
2 901035 3/8-16 flat socket head cap screws, zinc plated GR5
1 801170L rear support bracket, left side
1 801170R rear support bracket, right side
2 801171 front support brackets
1 801174L front support brace, left side
1 801174R front support brace, right side
4 #30 3” plastic rings, black
Step Two: Locate the JN420-S4L side bar, one 801171 support bracket, one 8011170L support bracket, two #30
plastic rings, three 901030 hex bolts, one 901035 flat socket bolt, three 901015 flat washers and three
901016 split lock washers. Secure the brackets and rings to the side bar as shown in fig #1. Do not
fully tighten hardware at this time.
