Installation Instructions
XRC Rock Sliders (Part #76890)
07-10 Jeep Wrangler
(2-Door)
Parts Included Qty
Parts Included Qty
10 x 25mm Hex Head Bolt 4
6 x 25mm Hex Head bolt 10
10mm Nut-Clip 4
6mm Ny-lock Nut 10
10mm Flat Washer 4
6mm Flat Washer 20
STEP 1: Remove factory rails/guards if equipped.
STEP 2: Identify the passenger and driver side rails. The half moon cut-outs go towards the rear of
the vehicle.
STEP 3: Insert two nut clips into body. (Fig A,) To identify proper placement hold the rock sliders
temporarily on the side of the vehicle and locate the two slotted holes on the bottom of the
sliders and note the hole location on the bottom of the body. There may be tape covering
the proper location for them, if so simply remove.
(Fig A)
NOTE: Carefully read instructions before installing this product. It is
recommended to have assistance while installing this product
Insert nut-clips into body
