Installation instructions – Smittybilt SB76882 XRC Rear Armor Corner Guard Kit User Manual
Page 3
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 W Artesia, Compton, CA 90220
Revised 02.08.11
Installation Instructions:
(Part # SB76882)
2007-2011 Jeep JK 4Door
XRC Rear Armor Corner Guard Kit
Previously Drilled
33/64” Holes with 3/8”
Nutcerts Installed
3/8” X 1”
SS Bolt
3/8” X 1”
Hex bolt
(Fig B)
Rear Armor
Fender 93-7037
drvr
3/8” X 1”
hex bolt
Rear Armor
Fender 93-7047
pass
3/8” X 1”
SS Bolt
3/8” X 1”
SS Bolt
(Fig C)
Previously Drilled
33/64” Holes with 3/8”
Nutcerts Installed
