Smittybilt SB76882 XRC Rear Armor Corner Guard Kit - Manual

For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 W Artesia, Compton, CA 90220
Revised 02.08.11
Installation Instructions:
(Part # SB76882)
2007-2011 Jeep JK 4Door
XRC Rear Armor Corner Guard Kit
NOTE: Carefully read entire instructions thoroughly before attempting to install this part.
INSTALLATION:
WARNING: Check with Local and State laws
before installing this accessory!
Parts Included: Qty
93-7037 Rear Armor Fender: Drvr 1
93-7047 Rear Armor Fender: Pass 1
93-7055 Fender Lip Guard: Drvr 1
93-7056 Fender Lip Guard: Pass 1
90-4324 Inner Fender Liner: Drvr 1
90-4325 Inner Fender Liner: Pass 1
93-7054 Liner Tab 4
90-6776 Hardware Pack: Fender 1
3/8” X 1” SS Button Head Bolt 37
3/8” Flat Washer 48
3/8” Nylock Nut 34
3/8”-16 X 1" Hex Bolt Gr. 5 13
Parts Included: Qty
90-6777 Hardware Pack: Inner Fender Liner 1
Plastic Retainers 14
90-6778 Hardware Pack: Nutcert 1
3/8” Nutcert 14
90-6774 Hardware Pack: Nutcert Installation 1
96-5951 Nutcert Tool 1
3/8” Star Washer 1
3/8” X 2” Socket Head Bolt 1
3/8” Gr. 8 Flat Washer 1
3/8” Gr. 8 Nut: Un-plated 1
90-6781 Hardware Pack: Fender Weather Stripping 1
90-4330 Fender Weather Stripping 1
IMPORTANT!: In order to install these fenders you will have to drill holes in
the body.
Step 1: Working on one side of the vehicle at a time, unbolt and remove the steps and/or
sliders from the vehicle. Save hardware for reinstallation.
Step 2: Remove the fender flairs and inner fenders from the vehicle.
Step 3: Remove the license plate box from the vehicle.
Step 4: Test fit the license plate template on the vehicle. Be sure the mounting holes and the
tailgate line up with the template. Due to factory manufacturing variations, the template may
need to be adjusted.
