Smittybilt SB76791 SRC JK Tubular front Doors User Manual

Installation instructions, Src jk tubular front doors

For Technical Support/Warranty Information please call 310-762-9944

Smittybilt, 400 W Artesia, Compton, CA 90220

Installation Instructions:

(Part # SB76791)

SRC JK Tubular front Doors

Revised 7.28.10

NOTE: Carefully read entire instructions thoroughly before attempting to install this part.

Step 1: Starting on the driver side of the vehicle, remove the (2) OE front door hinge retain-

ing nuts.

Step 2: Unplug the OE wiring harness from under the dashboard.

NOTE: Some early year models may have a red safety catch on the wiring plug. Pull

the red catch out one click and depress the black engagement tongue to release.

Step 3: Open the front door and unhook the door limit strap from the mount inside the vehi-

cle. New limit straps are provided in this kit.

Step 4: Carefully lift and remove the OE front door from the vehicle.

Step 5: Unbolt and remove the side view mirror from the OE door. Save the mirror and

hardware

for

reinstallation.

NOTE: Remove the side view mirror only not the entire mirror to door assembly.

Step 6: Install the supplied limit strap bracket (90-5868) onto the limit strap (769401).

Step 7: Slide the door hinges (93-5862 drvr and 93-5864 pass) into the OE mounting

brackets on the vehicle. Secure with the supplied 3/8” nuts.

Step 8: Carefully install the front door assembly (93-8064 and 93-8068) onto the previously

installed hinges using the (4) supplied 3/8” X 1” stainless bolts and hardware from pack (90-
6738). Install the limit strap (769401) and bracket (90-5868) to the lower hinge bolts as well.
Leave the bolts snug only at this time.

INSTALLATION:

Parts Included Qty

93-8064 Driver Side Door 1

93-8068 Passenger Side Door 1

93-5862 Door Hinge 2

93-5864 Door Hinge 2

93-5866 Mirror Bracket 2

90-5868 Limit Strap Bracket 2

769401 Limit Strap 2

90-6738 Hardware Pack:

Tube Door

3/8” X 1” SS Button Head Bolt 12

Parts Included Qty

3/8” Flat Washer 24

3/8” Nylock Nut 12

3/8” Hex Nut 4

90-6744 Hardware Pack:

Mirror

8mm-1.25 X 20mm SS Button Head Bolt 2

8mm SS Flat Washer 2

90-6766 Hardware Pack:

Tube Door

90-4263 Rubber Bumper 2
