Installation instructions, G.e.a.r. overhead console – Smittybilt 56660xx G.E.A.R. Overhead Console User Manual
Page 4

WWW.SMITTYBILT.COM
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
G.E.A.R. Overhead Console
07-10 Wrangler/Unlimited
(Part # 56660xx)
Step 9: Tighten the front windshield adapter bracket to the windshield completely at this time. (Fig C)
Step 10: Now re-install the front windshield trim piece you removed in Step 1. (Fig I)
(Fig I)
(Fig J)
Step 11: Make sure main plate is centered and or parallel with the vehicle and then proceed to tighten the
front bolt and rear sport bar clamp rings completely.
Step 12: Now place the cover over your frame and secure by fastening the top Velcro straps (Fig J, K)
(Fig K)
(Fig L)
Now re-install the front windshield trim piece you
previously removed. Use care when re-installing, it is a
snug fit.
