Smittybilt TN1120-S2X SIDEBAR User Manual
Page 3
Page 3 of 3
8/1/07 (AM)
(99-03 Extended Cab Passenger Side Installation Shown)
Bolt Plate
Plastic
Retainer
(Bolt Plate)
12mm Lock Washer
12mm Flat Washer
12mm Hex Nut
(Bolt Plate)
12mm Lock Washer
12mm Flat Washer
12mm Hex Nut
10mm x 45mm Hex Bolts
10mm Lock Washer
10mm Flat Washer
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
