Installation instructions – Smittybilt FN1700-S4 Sure Steps User Manual
Page 2

For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Page 2 of 3
Installation Instructions
Sure-Step (Part # FN1700-S4)
99-08 Ford Super Duty Crew Cab
Front Driver Side Bracket Shown
Rear Driver Side Bracket Shown
Disregard
hole
1/2”*2” Hex Bolt, 1/2”
Lock Washer, & 1/2”
Flat Washer
Front Driver Side Bracket Shown
Figure 4
Figure 5
Disregard
hole
Clip Nut, 10mm x
40mm Hex Bolt, 10mm
Lock Washer, & 10mm
Flat Washer
10mm x 40mm Hex
Bolt, 10mm Lock
Washer, 10mm Flat
Washer, 10mm Nut
Clip Nut, 10mm x
40mm Hex Bolt, 10mm
Lock Washer, & 10mm
Flat Washer
10mm x 40mm Hex
Bolt, 10mm Lock
Washer, 10mm Flat
Washer, 10mm Nut
Rear Driver Side Bracket Shown
Figure 2
Figure 3
