BEFORE OPERATION

HOW TO OPERATE ON-SCREEN MENU

FLOW OF ON-SCREEN MENU

Display ON-SCREEN MENU

Press MENU button to display the ON-SCREEN MENU (MENU
BAR). The red frame is the POINTER.

Select the ITEM by pressing SELECT button. The dialog box of
the ITEM appears.

Move the POINTER (red frame) to the ITEM ICON that you want
to select by pressing POINT RIGHT/ LEFT buttons.

Move the POINTER to the ITEM that you want to adjust and
adjust the ITEM by pressing SELECT button.
Refer to the following pages for details of respective adjustments.

Move the POINTER downward by pressing POINT DOWN button.
(The shape of the POINTER becomes an arrow.)

Select the MENU

Control and adjust through ON-SCREEN MENU

You can control and adjust this projector through the ON-SCREEN
MENU. Refer to the following pages to operate each adjustment on the
ON-SCREEN MENU.

1 MOVING THE POINTER

2 SELECT THE ITEM

Move the pointer (see the NOTE below) by pressing POINT button(s)
on the Top Control or on the Remote Control Unit.

Select the item by pressing SELECT button.

SELECT

SELECT

BUTTON

POINT

DOWN

BUTTON

MENU BAR

POINTER
(red frame)

ITEM ICON

POINTER
(red frame)

POINTER

Used to select the item.

SELECT BUTTON

Used to move the Pointer
UP/ DOWN/ RIGHT/
LEFT.

POINT BUTTONS

Used to select the item.

SELECT BUTTON

Used to move the
Pointer UP/ DOWN/
RIGHT/ LEFT.

POINT BUTTON

WIRELESS REMOTE CONTROL

TOP CONTROL

OPERATING ON-SCREEN MENU

NOTE : Pointer is the icon on the ON-SCREEN Menu to select the

item. See the figures on the section "FLOW OF ON-SCREEN
MENU" below.
