Connecting the projector – BOXLIGHT CP-14t User Manual
Page 13
13
B
A
COMPUTER IN
MONITOR OUT
CONTROL PORT
AUDIO IN
SERIAL
AUDIO OUT
(MONO)
VIDEO
R-AUDIO-L
S-VIDEO
CONNECTING THE PROJECTOR
To disconnect MOUSE CABLE,
1. Hold the portion (B) of the
connector with one hand.
2. Pull the portion (A) to the
arrow direction and remove
connector.
CONTROL PORT
AUDIO OUT
AUDIO IN
MONITOR OUT
COMPUTER IN
SERIAL
Use either of these Mouse Cables corresponding
with your terminal of your computer.
