INSTALLATION INSTRUCTIONS FOR S.R.S.™ 8795-50
PLEASE READ TERMS / POLICIES BEFORE INSTALLING KIT.
This “Kit” contains the following items:
ITEM
DESCRIPTION
QTY.
PART NUMBER
A
Bracket Plate-DS Drivers Side
1
87950-DS
B
Bracket Plates-PS Passenger Side
3
87950-PS
C
Bracket “L” front PS & DS
2
87950-F
D
Bracket slotted PS & DS
2
87950-R
E
Bushing-Aluminum
4
8795-125
F
Tube Spacer 3/4 OD X 2-¾ long
1
S101299
H
Bolt-Spring Pivot ft. 9/16”x4-1/2”
2
13271
I
Bolt-Bracket to Frame 1/2”x4-1/2”
3
13221
K
Bolt-Pivot Bracket to Frame 1/2”x1-1/4” 2
13207
L
Nut-Crimplock 9/16”
2
37270
M
Nut-Crimplock 1/2”
5
37268
N
Washer-Flat 9/16”
4
33088
O
Washer-Flat 1/2”
12
33086
-
Instruction Sheet
1
8795-50-IS
Please familiarize yourself with all components in this “Kit“. The instructions will refer to the item by letter not
description. Read all instructions carefully before work is started an your vehicle. In addition to basic hand
tools, the following specialty tools are needed to perform this installation: Power Drill (1/2" chuck), ¾” diameter
drill bit with 1/2" shank, ½” diameter drill bit, floor jack, jack stands (4), torque wrench, welder (M.I.G. pre-
ferred).
MOUNTAIN OFF ROAD ENTERPRISES INC.
P.O. BOX 690, DELTA, COLORADO 81416
970-625-0500
970-625-3747 fax
E-mail: [email protected]
PAGE 1 of 5
