Mountain Off Road 7686-FWK2.5 - Manual

ITEM: DESCRIPTION: SIZE: QTY: PART #
A BRACKET-PIVOT DS 1 7686-FWBDS
B BRACKET-PIVOT PS 1 7686-FWBPS
C-1 FRAME SPACER PLATE 3”X6”-1/4”2 HOLES 4 7686-FS
C-2 FRAME SPACER PLATE 3”X6”-1/8”2 HOLES 2 7686-TFS
D BOLT-BRACKET DS 7/16-14X1-1/2 2 15159
E BOLT-BRACKET PS 7/16-14X1-1/4 6 15157
F BOLT-BRACKET 5/8-11X2 2 15311
G NUT-BRACKET BOLT 5/8-11 4 37036
H BOLT-BRACKET 5/8-11X4 2 13319
I BOLT-SPRING 9/16-12X4-1/2 2 13271
J NUT-SPRING BOLT 9/16-12 2 37270
K TUBE-SPACER FRAME 7/8X1-7/8X.120 2 S107686
L WASHER-FLAT 7/16 SAE 12 33084
M WASHER-LOCK 7/16 SPLIT 4 33624
N NUT-SHACKLE HANGER 7/16-14Crimp Nut 4 37266
O WASHER-FLAT 9/16 SAE 4 33088
P WASHER-FLAT 5/8 SAE 8 33090
Q SHACKLE HANGER 2 FSH25
R SHACKLE HANGER BRACKET 2 7686-SHB
- INSTRUCTION SHEET 1 7686-FWK2.5
INSTALLATION INSTRUCTIONS FOR M.O.R.E.™ FULL WIDTH AXLE SHACKLE
REVERSAL SYSTEM
(S.R.S.™)
WITH 2.5” YJ SPRINGS.
PART # 7686-FWK2.5
THIS SYSTEM FITS 1976-1986 Jeep® CJ-5, CJ-7, CJ-8 VEHICLES.
Please read all instructions carefully (including terms-policies) before work is started on your vehi-
cle. Familiarize your self with all components in this system. These instructions will refer to all
items by letter not description. In addition to basic hand tools, the following specialty tools are
needed to perform this installation: Welder (220Volt Recommended), Oxy/Acetylene cutting torch,
grinder, floor jack, jack stands (4), torque wrench, 15/16” wrench & socket.
NOTES: SRS may not be compatible on Jeeps with Nerf Bars or any type of side bars that attach
to the frame at the point in which the shackles will be hung from.
Some aftermarket headers may cause interference with the SRS.
MOUNTAIN OFF ROAD ENTERPRISES
LLC.
P O BOX 690, DELTA, COLORADO 81416
970-625-0500
E-mail: [email protected]
S.R.S.™ # 7686-FWK2.5 contains the following items:
7686– FWK2.5 PAGE 1
