MOUNTAIN OFF ROAD ENTERPRISES. INC.
P.O. BOX 690
DELTA, COLORADO 81416
970-625-0500
E-mail: [email protected]
www.mountainoffroad.com
M.O.R.E. Shackle Reversal System (S.R.S.™) # 8795-3 contains the following items:
ITEM
DESCRIPTION
QUANTITY
PART NUMBER
A
Pivot Bracket-Drivers Side
1
8795-DS
B
Pivot Bracket-Pass Side
1
8795-PS
C
Bushing-Aluminum
4
8795-125
D
Tube Spacer 3/4”x2-3/4”
1
S101299
E
Bolt-Spring Pivot 9/16”X4-1/2”
2
13271
F
Bolt-Pivot Bracket to Frame 1/2”x4-1/2” 5
13221
G
Bolt-Pivot Bracket to Frame 1/2”x1-1/4” 2
13207
H
Nut-Crimp Lock 9/16”
2
37270
I
Nut-Crimp Lock 1/2”
7
37268
J
Washer-Flat 1/2”
12
33086
K
Washer-Flat 9/16”
4
33088
L
Shackle Side Plates
4
9040
M
YJ Frame Tubes
2
8795-ST25
N
Bushings
4
MO2221
O
Bushing Sleeves
2
S10222
Photo of items on page 2 of these instructions. Please familiarize yourself with all components in the system.
These instructions will refer to items by letter, not description. Read all instructions carefully before work is
started on your vehicle. In addition to basic hand tools, the following specialty tools are needed to perform this
installation: Angle head drill (electric or air), 3/4” diameter drill bit, 1/2” diameter drill bit, 21/64” drill bit, 3/8-24
(fine thread) tap, floor jack, jack stands (4), torque wrench, grinder and or cutting torch.
8795-3 PAGE 1
INSTALLATION INSTRUCTIONS FOR 8795-3
PLEASE READ AND UNDERSTAND TERMS/POLICIES BEFORE YOU INSTALL THIS SYSTEM
FIT and TOLERANCES: All parts in this system are the results of countless hours of research, testing, fitting
and refining. Jeep® frames have a wide tolerance on bolt hole centers from frame to frame. This is why
M.O.R.E.™ has installed several “slots” in which to mount our bracketry. In addition to the factory tolerances,
most people install other then factory equipment such as bumpers, winch mounts, springs etc. M.O.R.E.™ has
done the best job we can to insure that our parts fit with the different possibilities. However, you may find it nec-
essary to grind, elongate, bend, or force the parts in this system to fit on your rig. Please use common sense
when installing these parts, and understand that if you modify them in any way, they are not returnable!!
