——— STEP BY STEP INSTRUCTIONS TO INSTALL THE TJ SPORT CAGE ————
PHOTO PAGE 1:
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4
FIGURE 5 FIGURE 6
FIGURE 7
FIGURE 8
14. Tighten the floor plate bolts (9/16”) to 50 Lb. Ft. Tighten the #40 Torx® head bolts at the factory roll bar
to 30 Lb. Ft. Tighten the #40 Torx® head bolts on the W/S frame to a bit past snug. (Do not over tighten!)
Tighten the cross bar bolts (3/8”) to 30 Lb. Ft. Tighten the #50 Torx® head (tamperproof) to 35 Lb. Ft.
15. If carpet equipped, trim it to fit around the cage bars. See Figure 15. Re-zip the factory padding on the
roll bar. The Sport Cage installation is now completed. Please call or E-mail with any questions. Thank
you for purchasing this product from M.O.R.E.™.
