Mountain Off Road JKST07 - Manual (Page 2)

STEP 1A: Locate the 2 holes in the body pinch seam near the center of the front
door. ( See figure 5) Install the u-nut into the hole in the body directly behind the 2
holes in the pinch seam. (See figure 6)
STEP 2A: Insert the 1/4”x3/4” bolts with washers through the pinch seam and the
step base. Install washers and nuts onto these bolts. Install The 8MM button head
bolt through the back hole on the step base. (See figure 2 and 3A) Tighten all Hard-
ware.
STEP 3A: Line up the holes in the step and insert the two pins to complete assembly
(see figure 4)
STEP 4A: The step has raised dimples to provide traction but care should be taken
during use to prevent slippage. Mud, ice, and snow will make the step slicker. You
are now done so GO JEEPIN!
Figure1
Figure2
PAGE 2
