Lukas SC 357 E2 - Manual (Page 37)

37
11. Technical data
11.1 eDRAULIC cutter
Device type S 311 E2 S 700 E2
Item number
90-20-22 90-20-72
Dimensions (excluding
battery)
L x W x H
[mm] 847 x 225 x 262 920 x 296 x 262
[in.] 33.4 x 8.86 x 10.3 36.2 x 11.7 x 10.3
Max. cutting opening
[mm] 150 192
[in.] 5.9 7.6
Mass (excl. battery)
[kg] 17.7 21.8
[lbs.] 39 48.1
Nominal electrical voltage
(with power supply)
[V] 24
Nominal electrical voltage
(with lithium-ion battery)
[V] 25.2
Protection category IP 54
Classifi cation (NFPA 1936) A7/B8/C6/D7/E7 A8/B9/C8/D9/E9
NOTE:
The following tables contain only the technical data necessary for operation and
storage.
Further information about your device is available directly from LUKAS.
Since all values are subject to tolerances, minor differences may occur between the data on
your equipment and the data in the following tables.
The values may also differ because of reading inaccuracies and/or tolerances in the
measuring equipment used.
Operating pressure: S 311 E2: 75 MPa
S 700 E2: 80 MPa
SP 300 E2: 80 MPa
SP 310 E2: 75 MPa
SC 250 E2: 70 MPa
SC 357 E2: 70 MPa
R 411 E: 70 MPa
