26
2. Remove the two fi xing screws "A" and
remove the protective cover "B". To do
this, fi rst pull the rounded rear edge
outwards and then backwards through
the hand grip, as the edges of the
protective cover adjoining the cylinder
body are kept in place by guide grooves.
If necessary, loosen the hand grip and
move it backwards to obtain suffi cient
space to pull it out. Then remove the
cover caps "C".
3. Move the blade arms on the unit until
the pin "E" and the locking rings "F"
can be accessed through the hole "D".
Now switch off the device and
remove the battery or unplug the
power supply from the device.
A
B
B
C
C D
Work steps:
1. First of all, carefully clean the rescue equipment.
E
F
B
B
CAUTION / PLEASE NOTE!
When operating the device with
the hand guard removed, there is
an increased risk of injury caused
by the exposed, moving elements.
