Bryant PREFERRED 581J - Manual (Page 41)

41
TABLE 35 – 581J*06A Horizontal Unit--Direct Drive
Speed
(Torque)
tap
CFM ESP BHP
1
1500 0.40 0.50
1625 0.20 0.48
1750 0.04 0.45
1875 --- ---
2000 --- ---
2125 --- ---
2250 --- ---
2375 --- ---
2500 --- ---
2
1500 0.62 0.62
1625 0.39 0.60
1750 0.19 0.57
1875 0.03 0.53
2000 --- ---
2125 --- ---
2250 --- ---
2375 --- ---
2500 --- ---
3
1500 1.04 0.87
1625 0.87 0.88
1750 0.68 0.88
1875 0.48 0.84
2000 0.28 0.84
2125 0.07 0.84
2250 --- ---
2375 --- ---
2500 --- ---
4
1500 1.10 0.90
1625 0.96 0.94
1750 0.81 0.98
1875 0.65 0.95
2000 0.47 1.00
2125 0.27 0.94
2250 0.05 0.96
2375 --- ---
2500 --- ---
5
1500 1.12 0.92
1625 1.00 0.96
1750 0.81 1.00
1875 0.65 1.04
2000 0.56 1.08
2125 0.39 0.95
2250 0.19 1.09
2375 --- ---
2500 --- ---
TABLE 36 – 581J*06A Vertical Unit--Direct Drive
Speed
(Torque)
tap
CFM ESP BHP
1
1500 0.27 0.45
1625 0.08 0.43
1750 --- ---
1875 --- ---
2000 --- ---
2125 --- ---
2250 --- ---
2375 --- ---
2500 --- ---
2
1500 0.48 0.57
1625 0.26 0.55
1750 0.08 0.53
1875 --- ---
2000 --- ---
2125 --- ---
2250 --- ---
2375 --- ---
2500 --- ---
3
1500 0.91 0.82
1625 0.72 0.82
1750 0.52 0.81
1875 0.31 0.78
2000 0.11 0.77
2125 --- ---
2250 --- ---
2375 --- ---
2500 --- ---
4
1500 0.98 0.85
1625 0.82 0.89
1750 0.66 0.92
1875 0.50 0.90
2000 0.32 0.92
2125 0.13 0.86
2250 --- ---
2375 --- ---
2500 --- ---
5
1500 1.00 ---
1625 0.86 0.91
1750 0.66 0.95
1875 0.50 0.98
2000 0.41 1.01
2125 0.25 0.88
2250 0.06 1.01
2375 --- ---
2500 --- ---
581J
