10
TABLE 5 – HEATING RATING TABLE -- LOW NO
X
1
UNIT GAS HEAT
LOW NOx HEAT EXCHANGER
TEMP RISE
(DEG F)
THERMAL
EFFICIENCY
(%)
AFUE
(%) INPUT / OUTPUT
STAGE 1 (MBH)
INPUT / OUTPUT
STAGE 2 (MBH)
Sin
gle
Pha
se
04
LOW --- 60 / 50 20 --- 50 81% 80%
MED --- 90 / 74 30 --- 60 81% 81%
HIGH --- --- --- --- ---
05
LOW --- 60 / 50 20 --- 50 81% 80%
MED --- 90 / 74 30 --- 60 81% 81%
HIGH --- 120 / 101 40 --- 70 81% 80%
06
LOW --- 60 / 50 15 --- 50 81% 80%
MED --- 90 / 74 25 --- 60 80% 81%
HIGH --- 120 / 101 35 --- 70 80% 81%
Th
re
e
P
ha
se
04
LOW --- 60 / 50 20 --- 50 81% 80%
MED --- 90 / 74 30 --- 60 81% 81%
HIGH --- --- --- --- ---
05
LOW --- 60 / 50 20 --- 50 81% 80%
MED --- 90 / 74 30 --- 60 81% 81%
HIGH --- 120 / 101 40 --- 70 81% 80%
06
LOW --- 60 / 50 15 --- 50 81% 80%
MED --- 90 / 74 25 --- 60 80% 81%
HIGH --- 120 / 101 35 --- 70 80% 81%
NOTE:
1. Units meet California’s South Coast Air Quality Management District (SCAQMD) Low---NO
x
emissions requirement of 40
nanograms per joule or less.
TABLE 6 – SOUND PERFORMANCE TABLE
UNIT
COOLING
STAGES
OUTDOOR SOUND (dB) AT 60
A---WEIGHTED 63 125 250 500 1000 2000 4000 8000
04A 1 76 78.2 78.0 74.2 73.3 70.6 66.0 62.4 56.9
05A 1 78 84.7 83.6 77.1 74.6 72.3 68.3 64.7 60.9
06A 1 77 87.5 82.5 76.1 73.6 71.3 67.1 64.1 60.0
07A 1 82 90.1 82.6 81.0 79.4 77.0 73.0 70.4 66.7
08D 2 82 90.6 84.3 80.2 79.3 77.1 72.2 67.4 63.7
09D 2 82 88.6 85.0 81.6 79.5 77.4 74.1 71.0 66.3
LEGEND
dB --- Decibel
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
NOTES:
1. Outdoor sound data is measure in accordance with
AHRI.
2. Measurements are expressed in terms of sound power.
Do not compare these values to sound pressure values
because sound pressure depends on specific environ-
mental factors which normally do not match individual
applications. Sound power values are independent of
the environment and therefore more accurate.
3. A---weighted sound ratings filter out very high and very
low frequencies, to better approximate the response of
“average” human ear. A---weighted measurements for
Bryant units are taken in accordance with AHRI.
581J
