TABLE 15 – COOLING CAPACITIES 1--STAGE COOLING 6 TONS
581J*07A
AMBIENT TEMPERATURE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
1800
Cfm
EA
(wb)
58
THC 64.1 64.1 72.5 61.8 61.8 69.9 59.2 59.2 67 56.3 56.3 63.7 53.2 53.2 60.2
SHC 55.7 64.1 72.5 53.7 61.8 69.9 51.4 59.2 67 48.9 56.3 63.7 46.2 53.2 60.2
62
THC 67.9 67.9 68.5 64.9 64.9 67 61.5 61.5 65.3 57.9 57.9 63.5 54 54 61.4
SHC 50.2 59.4 68.5 48.8 57.9 67 47.1 56.2 65.3 45.4 54.4 63.5 43.4 52.4 61.4
67
THC 74.8 74.8 74.8 71.5 71.5 71.5 67.8 67.8 67.8 63.8 63.8 63.8 59.5 59.5 59.5
SHC 41.8 50.9 60.1 40.3 49.5 58.7 38.8 47.9 57.1 37.1 46.2 55.4 35.3 44.4 53.6
72
THC 82.2 82.2 82.2 78.7 78.7 78.7 74.7 74.7 74.7 70.4 70.4 70.4 65.6 65.6 65.6
SHC 33 42.3 51.6 31.6 40.9 50.2 30.1 39.3 48.6 28.4 37.7 46.9 26.7 35.9 45.1
78
THC --- 88.7 88.7 --- 84.8 84.8 --- 80.6 80.6 --- 76 76 --- 70.9 70.9
SHC --- 35.3 45.2 --- 33.9 43.7 --- 32.4 42 --- 30.7 40.3 --- 28.9 38.5
2100
Cfm
EA
(wb)
58
THC 67.6 67.6 76.5 65.1 65.1 73.7 62.3 62.3 70.5 59.3 59.3 67.1 55.9 55.9 63.2
SHC 58.7 67.6 76.5 56.6 65.1 73.7 54.1 62.3 70.5 51.5 59.3 67.1 48.5 55.9 63.2
62
THC 70.1 70.1 74.9 67 67 73.2 63.5 63.5 71.3 59.7 59.7 69.1 56 56 65.8
SHC 53.9 64.4 74.9 52.4 62.8 73.2 50.6 61 71.3 48.7 58.9 69.1 46.2 56 65.8
67
THC 77.1 77.1 77.1 73.6 73.6 73.6 69.7 69.7 69.7 65.5 65.5 65.5 60.9 60.9 60.9
SHC 44.2 54.8 65.3 42.7 53.3 63.9 41.2 51.7 62.3 39.4 50 60.5 37.6 48.1 58.6
72
THC 84.7 84.7 84.7 80.9 80.9 80.9 76.8 76.8 76.8 72.2 72.2 72.2 67.2 67.2 67.2
SHC 34.2 44.8 55.5 32.7 43.4 54 31.1 41.8 52.4 29.5 40.1 50.7 27.6 38.2 48.8
76
THC --- 91.3 91.3 --- 87.2 87.2 --- 82.7 82.7 --- 77.8 77.8 --- 72.5 72.5
SHC --- 36.7 47.8 --- 35.3 46.3 --- 33.7 44.7 --- 32 43 --- 30.2 41.1
2400
Cfm
EA
(wb)
58
THC 70.6 70.6 79.9 68 68 76.9 65 65 73.5 61.7 61.7 69.8 58.1 58.1 65.8
SHC 61.3 70.6 79.9 59 68 76.9 56.4 65 73.5 53.6 61.7 69.8 50.5 58.1 65.8
62
THC 72 72 80.6 68.7 68.7 78.7 65.2 65.2 76.6 61.8 61.8 72.6 58.2 58.2 68.4
SHC 57.3 69 80.6 55.6 67.2 78.7 53.7 65.2 76.6 50.9 61.8 72.6 48 58.2 68.4
67
THC 78.9 78.9 78.9 75.2 75.2 75.2 71.2 71.2 71.2 66.8 66.8 66.8 62 62 63.4
SHC 46.5 58.4 70.3 45 56.9 68.8 43.4 55.3 67.2 41.6 53.5 65.4 39.7 51.6 63.4
72
THC 86.6 86.6 86.6 82.7 82.7 82.7 78.3 78.3 78.3 73.6 73.6 73.6 68.4 68.4 68.4
SHC 35.2 47.2 59.2 33.7 45.7 57.7 32.1 44.1 56 30.4 42.3 54.3 28.5 40.5 52.4
78
THC --- 93.3 93.3 --- 89 89 --- 84.4 84.4 --- 79.3 79.3 --- 73.7 73.7
SHC --- 38 50.4 --- 36.6 48.9 --- 35 47.3 --- 33.3 45.5 --- 31.4 43.6
2700
Cfm
EA
(wb)
58
THC 73.2 73.2 82.8 70.4 70.4 79.6 67.3 67.3 76.1 63.8 63.8 72.2 60 60 67.9
SHC 63.6 73.2 82.8 61.1 70.4 79.6 58.4 67.3 76.1 55.4 63.8 72.2 52.1 60 67.9
62
THC 73.7 73.7 85.5 70.5 70.5 82.8 67.3 67.3 79.1 63.9 63.9 75.1 60.1 60.1 70.6
SHC 60.2 72.9 85.5 58.1 70.5 82.8 55.5 67.3 79.1 52.7 63.9 75.1 49.5 60.1 70.6
67
THC 80.3 80.3 80.3 76.5 76.5 76.5 72.4 72.4 72.4 67.8 67.8 70 62.9 62.9 67.9
SHC 48.7 61.9 75.1 47.1 60.4 73.6 45.5 58.7 71.9 43.7 56.8 70 41.7 54.8 67.9
72
THC 88.2 88.2 88.2 84 84 84 79.6 79.6 79.6 74.6 74.6 74.6 69.3 69.3 69.3
SHC 36.1 49.4 62.7 34.6 47.9 61.2 33 46.2 59.5 31.2 44.5 57.7 29.3 42.6 55.8
78
THC --- 94.9 94.9 --- 90.4 90.4 --- 85.6 85.6 --- 80.4 80.4 --- 74.7 74.7
SHC --- 39.2 52.9 --- 37.7 51.4 --- 36.1 49.7 --- 34.4 47.9 --- 32.5 46
3000
Cfm
EA
(wb)
58
THC 75.4 75.4 85.3 72.5 72.5 82 69.2 69.2 78.3 65.6 65.6 74.2 61.7 61.7 69.8
SHC 65.5 75.4 85.3 62.9 72.5 82 60.1 69.2 78.3 57 65.6 74.2 53.5 61.7 69.8
62
THC 75.5 75.5 88.7 72.5 72.5 85.3 69.3 69.3 81.4 65.7 65.7 77.2 61.7 61.7 72.5
SHC 62.2 75.5 88.7 59.8 72.5 85.3 57.1 69.3 81.4 54.1 65.7 77.2 50.9 61.7 72.5
67
THC 81.4 81.4 81.4 77.5 77.5 78.1 73.3 73.3 76.4 68.7 68.7 74.4 63.7 63.7 72.2
SHC 50.7 65.2 79.7 49.2 63.7 78.1 47.5 61.9 76.4 45.6 60 74.4 43.6 57.9 72.2
72
THC 89.4 89.4 89.4 85.2 85.2 85.2 80.5 80.5 80.5 75.5 75.5 75.5 70.1 70.1 70.1
SHC 36.9 51.5 66.1 35.4 50 64.6 33.8 48.3 62.9 32 46.5 61.1 30.1 44.6 59.1
78
THC --- 96.1 96.1 --- 91.6 91.6 --- 86.7 86.7 --- 81.3 81.3 --- 75.5 75.5
SHC --- 40.4 55.3 --- 38.9 53.8 --- 37.2 52.1 --- 35.5 50.3 --- 33.6 48.3
LEGEND:
--- --- Do not operate
Cfm --- Cubic feet per minute (supply air)
EAT(db) --- Entering air temperature (dry bulb)
EAT(wb) --- Entering air temperature (wet bulb)
SHC --- Sensible heat capacity
TC --- Total capacity
581J
