16
CURBS & WEIGHTS DIMENSIONS -- 581J04--06
NOTES:
1. DIMENSIONS ARE IN INCHES, DIMENSIONS
IN [ ] ARE IN MILLIMETERS.
2. CENTER OF GRAVITY
3.
DIRECTION OF AIR FLOW
44
25
636 [ ]
18-1/8
459 [ ]
12-1/4
312 [ ]
14-1/4
363 [ ]
16-1/8
411 [ ]
SUPPLY
AIR
17-3/4
451 [ ]
12-1/8
307 [ ]
10-7/8
277 [ ]
RETURN AIR
25-5/8
652 [ ]
33-3/8
848 [ ]
16
406 [ ]
1117]
26-1/2
673 [ ]
6-1/4
157 [ ]
29-3/8
747 [ ]
32-1/4
818 [ ]
3-3/8
85 [ ]
18-1/2
470 [ ]
4
100 [ ]
ECONOMIZER HOOD
(OPTIONAL)
RETURN
AIR
SUPPLY
AIR
TOP
SEE THRU THE
BASE CHART
E ALT.
CONDENSATE
DRAIN OPENING
IN BASEPAN
C
FLUE
HOOD
W
X
Y
Z
21-1/4
539 [ ]
26-3/4
681 [ ]
7
177 [ ]
RETURN
AIR
25-1/8
638 [ ]
10-1/2
265 [ ]
SUPPLY AIR
16-3/4
427 [ ]
11-3/8
289 [ ]
6-1/8
155 [ ]
6
152 [ ]
31-1/4
793 [ ]
6-5/8
168 [ ]
1-1/4
32 [ ]
RETURN
AIR
SUPPLY
AIR
RIGHT
OUTSIDE
AIR
BAROMETRIC
RELIEF
FLOW
E STD.
CONDENSATE
DRAIN
FILTER
J
30-1/8
764 [ ]
8-3/8
213 [ ]
74-3/8
1888 [ ]
INDOOR BLOWER
ACCESS
CONTROL BOX
ACCESS PANEL
FRONT
F
OPTIONAL
FACTORY
INSTALLED
DISCONNECT
HANDLE
HANDLE
19-1/2
494 [ ]
6-5/8
168 [ ]
4-5/8
118 [ ]
K
46-3/4
1187 [ ]
3-3/4
95 [ ]
CONDENSER
COIL
LEFT
ELECTRICAL
DISCONNECT
LOCATION
A,
B,
G
D
OPTIONAL
FACTORY
INSTALLED
CONVENIENCE
OUTLET
2-5/8
67 [ ]
BACK
INDOOR COIL
ACCESS PANEL
FILTER ACCESS PANEL
(TOOL-LESS)
TYP
CURB
WIDTH
COMP.
ACCESS
PANEL
CONDENSER
COIL
CONNECTION SIZES
A 1 3/8" [35] DIA FIELD POWER SUPPLY HOLE
B 2" [50] DIA POWER SUPPLY KNOCKOUT
C 1 3/4" [51] DIA GAUGE ACCESS PLUG
D 7/8" [22] DIA FIELD CONTROL WIRING HOLE
E 3/4"-14 NPT CONDENSATE DRAIN
F 1/2"-14 NPT GAS CONNECTION
G 2 1/2 " [64] DIA POWER SUPPLY KNOCK-OUT
THRU-THE-BASE CHART
THESE HOLES REQUIRED FOR USE
CRBTMPWR001A01, 003A01
THREADED
CONDUIT SIZE
WIRE
USE
REQ'D HOLE
SIZES (MAX.)
W 1/2" ACC. 7/8" [22.2]
X 1/2" 24V 7/8" [22.2]
Y * 3/4" (001,003) POWER 1 1/8" [28.4]
Z** (003) 1/2" FPT GAS 1 3/16" [30.0]
FOR "THRU-THE-BASEPAN" FACTORY OPTION,
FITTINGS FOR ONLY X,Y, & Z ARE PROVIDED
*
SELECT EITHER 3/4" OR 1/2"
FOR POWER, DEPENDING ON WIRE SIZE
**
(001) PROVIDES 3/4" FPT THRU CURB
FLANGE & FITTING.
UNIT J K
33 3/8
[847]
18 5/8
[472]
41 3/8
[1051]
14 7/8
[377]
41 3/8
[1051]
14 7/8
[377]
581J-04A
581J-05A
581J-06A
C10378
Fig. 1 -- Dimensions 581J04--06
581J
