ESB TDM and EXS24 TDM
With the ESB TDM and EXS24 TDM Logics provides you
with two plug-ins that enhance your TDM system.
The ESB TDM and EXS24 TDM expand your TDM mixer—controlled by Logic Pro. If
working at 44.1/48 kHz, up to 32 additional channels are available. These extra channels
can be used for multiple EXS24 sampler instances and/or up to eight inputs routed
from DTDM, the native audio engine running in parallel to the DAE.
Features
The ESB TDM plug-in allows the routing of up to eight audio channels of the native
(computer CPU processing) DTDM mixer into the DSP-based TDM mixer.
This, in essence, is similar to having a card equipped with a multi channel digital output
installed in the computer, and physically connected to an additional multi channel
input module for your TDM system. The ESB TDM effectively replaces the audio card’s
digital outputs and driver, the TDM audio interface and the cables between them.
ESB TDM routes digital signals via software within the computer, with no need for any
additional hardware to be installed or cabled.
The EXS24 TDM plug-in allows the insertion of up to 32 mono/16 stereo EXS24
samplers in the uppermost Insert slots of Aux channel strips in the TDM mixer. Ensuing
Insert slots allow the sampler output signals to be further treated by TDM effect plug-
ins.
Note: The EXS24 TDM is available as a mono or stereo plug-in, but not as a
multichannel plug-in.
The maximum number of available Aux channels is 64. Any established configuration of
the first 32 Aux channel strips will remain as is.
