JB Conversions 16-1204 HD Standard Length SYE Kit for the NP241 User Manual
Page 11
11
18) Install the main sprocket assembly onto the new output shaft.
Retain this assembly with the new retaining ring supplied in the kit
(Fig.19).
FIG: 19
19) Install the mainshaft assembly into the case. Be sure to line up the
range fork as the mode fork is lowered into place with the mainshaft.
It may be necessary to slightly lift the lower range fork with you finger
as you lower the mainshaft/fork assembly into place. Do not force the
mainshaft assembly into place (Fig.20).
FIG: 20
