FORM-ENG-0018 REV A 05-27-03
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : 352-629-2902 or 1-800-520-3473
TECHNICAL DATA SHEET
PAGE 15 OF 16
DATE 10/1/2010
PRODUCT GROUP THROTTLE CONTROL P/N 119971 REV 1.20
PRODUCT Twister Electronic Throttle (Analog version) BY AMS
Manual P/N 120478
8. Technical Details
Product category Throttle control (analog)
Voltage range +9VDC…+32VDC
Maximum current draw
@13.8VDC
@27.6VDC
Logic supply+ input (pin 1 of 6-pin connector)
240 mA
163 mA
Temperature range -40ºF…+185ºF (-40ºC…+85ºC)
Environmental range IP 67
LED 2 LEDs (green and blue) to indicate status
Electrical protection
Internal thermal fuse (750mA on pin 1 of black 6-pin connector)
Transient voltage protected to SAE J1113 specification for heavy duty trucks (24V)
Load dump voltage protected to SAE J1113 specification for heavy duty trucks (24V)
Electrical performance
Immunity to Radiated Electromagnetic Fields– Bulk Current
Injection (BCI) method, Class C device
SAE J1113-4
Reverse voltage protection on power leads (pins 1 and 2 of 6-pin
connector), Class C device
ISO 16750-2
Overvoltage due to failing generator, Class A device ISO 16750-2
Immunity to conducted transients on power leads, Class C device
(24V)
SAE J1113-11
Immunity to Electrostatic Discharge – powered and unpowered
modes
SAE J1113-13
Immunity to radiated electromagnetic fields, Class C device SAE J1113-21
Conducted emission on power leads (level 3 limits) SAE J1113-41
Radiated emissions, absorber-lined shielded enclosure (level 2
limits)
SAE J1113-41
Reset behavior on voltage drop 24V, Class C device ISO 16750-2
Environmental performance
Thermal shock
SAE J1455
(sec 4.1.3.2)
Exposure to humidity
MIL-STD-810F
(method 507.4)
Thermal shock due to splash
Class 1
(STD-0001)
Pressure cleaning
SAE J1455
(sec 4.4)
Exposure to salt spray atmosphere/fog
SAE J1455
(sec 4.3)
Exposure to outdoor UV
ISO 4892-2
(method A)
Mechanical performance
Resonance dwell
SAE J1455
(sec 4.9.4.1)
Random vibration
SAE J1455
(sec 4.9.4.2)
Mechanical shock
SAE J1455
(sec 4.10.3.4)
Dimensions (W x H x D)
in inches [millimeters]
4.438 [112.73] x 3.188 [80.98] x 2.312 [58.74]
Weight in ounces [grams] 22.8 [646.4]
