AEM 30-6601 Series 2 Plug & Play EMS User Manual
Page 12
The EMS functions assigned to certain pins have been changed and no longer match the
30-1601 EMS. Unless otherwise noted, the following pins and functions will need to be
manually reconfigured after using AEMTuner to convert a V1.19 (30-1601, Series 1 EMS)
calibration for use with the 30-6601 Series 2 hardware.
Pin
Vehicle harness
destination
30-1601 function 30-6601 function
Notes
12
A/T Signal No. 3
Low Side 5
CAN1H
LS5 not available
15
Data Link Connector
Injector 8
EGT 2
Injector 8 available on pin 114
42
A/T Signal No. 1
Switch 1
CAN1L
Switch 1 not available
114
---
EGT 2
Injector 8
EGT 2 available on pin 15
Page 12 of 13
