AEM 30-3705 Infinity-6/8h Mini-Harness - Manual (Page 20)

AEM Infinity Harness Manuals 17
© 2014 AEM Performance Electronics
Infinity Pin Hardware Ref. Hardware Specification Notes
C1-48 +12V_SW 10K pulldown Full time battery power must be available at
C1-10 before this input is triggered.
C1-49 +5V_Out_1 Regulated, fused +5V supply for
sensor power Analog sensor power
C1-50 +5V_Out_1 Regulated, fused +5V supply for
sensor power Analog sensor power
C1-51 Analog_In_7 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced
to +12V as this can permanently damage the
ECU. See the Setup Wizard Set Throttle Range
page for automatic min/max calibration.
Monitor the Throttle [%] channel. Also
DB1_TPSA [%] for DBW applications.
C1-52 Analog_In_8 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced
to +12V as this can permanently damage the
ECU. See the Setup Wizard Set Manifold
Pressure page for setup and calibration.
Monitor the MAP [kPa] channel.
C1-53 Analog_In_9 12 bit A/D, 100K pullup to 5V 0-5V analog signal. Use +5V Out pins as power
supply and Sensor Ground pins as the low
reference. Do not connect signals referenced
to +12V as this can permanently damage the
ECU. See the Setup Wizard Fuel Pressure page
for setup and calibration. Monitor the
FuelPressure [psig] channel.
C1-54 VR+_In_2 Differential Variable Reluctance Zero
Cross Detection See Non Driven Wheel Speed Calibration in
the Setup Wizard Vehicle Speed page.
C1-55 VR-_In_2
C1-56 VR-_In_3 Differential Variable Reluctance Zero
Cross Detection See Driven Wheel Speed Calibration in the
Setup Wizard Vehicle Speed page.
C1-57 VR+_In_3
C1-58 HighsideSwitch_0 2.6A max, High Side Solid State Relay See Setup Wizard page 'HighSide Assigment
Tables' for configuration options. See 2D
lookup table 'HS0_Table' for activation
settings.
See Setup Wizard page 'VTEC' for
default activation criteria.
C1-59 Stepper_1B Automotive, Programmable Stepper
Driver, up to 28V and ±1.4A Be sure that each internal coil of the stepper
motor are properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only.
C1-60 Stepper_2B Automotive, Programmable Stepper
Driver, up to 28V and ±1.4A Be sure that each internal coil of the stepper
motor are properly paired with the 1A/1B and
2A/2B ECU outputs. Supports Bi-Polar stepper
motors only.
C1-61 DBW1 Motor - 5.0A max Throttle Control Hbridge
Drive +12V to close
C1-62 DBW1 Motor + 5.0A max Throttle Control Hbridge
Drive +12V to open
