For Your Safe Flight
Page 41
HP Constant
=
125
10
999
Hold NEXT and button 2 until you see
ADJUST. Tap PLUS or MINUS to adjust
(%HP display will reflect changes). Hold
NEXT and button 2 to save changes.
Engine Constant = 14.9 1
99.9
Hold NEXT and button until you see
ADJUST. Tap PLUS or MINUS to adjust.
Hold NEXT and button 2 to save changes.
Engine HP = 225
10
999
Set the nominal horsepower of your
engine. This value will be multiplied by the
%HP to display HP. Hold NEXT and button
2 for 5 seconds until you see ADJUST.
Use PLUS or MINUS to adjust. Tap SAVE
to save changes. Tap NEXT to skip to next
item.
Map Adjustment +0.0
-3.0
+3.0 Correct the MAP to the altimeter setting at
a sea level airport ±3.0 inHg. Hold NEXT
and button 2 for 5 seconds until you see
ADJUST. Use PLUS or MINUS to adjust.
Tap SAVE to save changes. Tap NEXT to
skip to next item.
K-Factor 1 29.90
00.10
99.99
Set the instrument’s K-factor to match the
fuel flow transducer K-factor and
performance. Hold DIGIT and button 2 for
5 seconds until you see ADJUST. Use
DIGIT, PLUS or MINUS to adjust. Hold
NEXT and button 2 to save changes.
GPS Format = 6
0
8
Adjust to set the GPS Communications
format. Hold NEXT and button 2 for 5
seconds until you see ADJUST. Use
PLUS or MINUS to adjust. Tap SAVE to
save changes. Tap NEXT to skip to next
item. See page 46.
Time: 18:23:59
00:00:00
23:59:59
Hold NEXT and button 2 for 5 seconds
until you see ADJUST. Use Hours,
Minutes, Seconds to adjust. Tap SAVE
to save changes. Tap NEXT to skip to next
item.
Date: 05/14/09
01/01/00
12/31/99
Hold NEXT and button 2 for 5 seconds
until you see ADJUST. Use Month, Day,
Year to adjust. Tap SAVE to save
changes. Tap NEXT to skip to next item.
END? Yes
END? Yes
Yes exits the pilot program mode.
No reenters pilot program mode.
