For Your Safe Flight
Page 40
Pilot Programming Mode
To start Pilot Program Mode, hold both
STEP
and
LF
buttons until you
see PROGRAM for two seconds. Then tap the
NEXT
button to advance
to the desired item in the list. Hold the
NEXT
button to back up in the
list. Either tap
NEXT
until you see END? Yes and then tap
EXIT
or hold
both
NEXT
and
LF
to save changes.
First button advances
to NEXT item
Second
button
selects
values
Comments
Program Mode
Stays on for two seconds.
Refuel?
Tap REFUEL to change fuel status.
Exits program mode when done.
Auto Scan Rate 4
0
9
Scan rate (seconds between
parameters) in the Automatic Mode.
0 disables the Automatic Mode.
Trip Used? No
NO
YES
NO: When Refuel mode used on EDM,
total fuel used is reset to 0.
YES: accumulate total fuel used rather
than reset to 0 at each refueling. See
page 43
EGT Display in 1’s
1’s
10’s
Tapping 1’s sets the digital display to
one-degree resolution; tapping 10’s
sets 10°. (10° resolution is easier to
interpret the EGTs.)
OAT Display ºF
F
C
Tap C to display OAT in Celsius, F to
display in Fahrenheit. Hold STEP and LF
for 5 seconds to ADJUST the OAT
calibration.
OAT Adjustment 0
-10
10
Adjust the indicated temperature up or
down by up to 10° using PLUS or MINUS.
For example, OAT
3 adjust the OAT 3°
higher.
HP Constants
Hold NEXT and button 2 for 5 seconds
until you see ADJUST rich of peak or lean
of peak constants. Tap ROP to proceed to
Rich of Peak ‘HP Constant’ setting. Tap
LOP to proceed to Lean of Peak ‘Engine
Constant’ setting.
