Operation
79 Model 8042 Rev. 11/03
3 Foot Truss Boom w/Winch Capacity Chart
4110376
8042
28
4
8 12 16 20 24 0 ft
28
0 ft
4
8
12
16
20
24
32
36
40
44
-4
16 21
27
A
B
C
D
E
40°
68°
0°
10°
20°
30°
50°
60°
-4°
ALWAYS
• travel slowly
• rig properly
• use two tethers
SWINGING LOADS can
cause MACHINE TIPOVER
which can result in death
or serious injury.
WITH SKY TRAK APPROVED
TRUSS BOOM WINCH ONLY SAFETY INSTRUCTIONS
Use only with vehicles
equipped with auxiliary
hydraulics.
Always connect couplers.
ASME B56.6 - 2002 PART lll
OH3580
