Page 36: Operation
34
Model 8042
Rev. 11/03
Operation
Hourmeter
The hourmeter (1) records engine operating hours and has a total readout
of 9,999.99 hours. It is located at the lower portion of the instrument cluster
(2) on the right side console.
Fuel Gauge
The fuel gauge (3) indicates the quantity of fuel in the fuel tank. The gauge
is located in the center of the instrument cluster (2) on the right side
console. Capacity of the fuel tank is 37 gallons (140 liters) total capacity
with a usable capacity of 35.6 gallons (135 liters).
Instruments and Indicators
OS0260
OH2470
0000 00
P
OH1810
3
1
2
