40 Model 8042 Rev. 11/03
Operation
Function Indicator Lights
There are two additional indicator lights located on the right side of the front
dash:
A. Engine Air-Intake Heater Indicator
The engine air-intake heater indicator light (1) located in the upper
switch bank on the right side of the front dash. This light illuminates,
with the ignition switch in the RUN position, any time the ambient
temperature drops below 40° F (4° C). The engine grid heater then
becomes active and the engine should not be cranked until the light
goes OFF. Once the light goes OFF it indicates that the grid heater
is at the proper temperature and the engine is ready to start.
NOTE: This indicator light may come ON when the engine is running to indi-
cate that the post heat function is active. This is a normal condition when
ambient temperatures are below 40° F (4° C).
OU0040
OH3280
1 2
4
3
