SECTION 1

SPECIFICATIONS

MODEL 6040 MAINFRAME CHARACTERISTICS

Timing Characteristics

INTERNAL REP RATE

Range:

0.01 Hz – 100 MHz

Resolution:

4 digits

Accuracy:

0.01%

DELAY

Range:

0 – 640 s.

Resolution:

1 ns or 5 digits, whichever is greater.

Jitter (rms):

25 ps or 0.01% of Delay, whichever is greater.

Accuracy:

0 to 9 ns. 1 ns; 10 ns to 640 s, 0.5 ns or 0.2% of Delay,
whichever is greater.

WIDTH

Range:

3 ns – 640 s.

Resolution:

1 ns or 5 digits, whichever is greater.

Jitter (rms):

25 ps or 0.01% of Width, whichever is greater.

Accuracy:

Width, whichever is greater.

PULSE SPACING

Minimum Pulse Separation: For Widths < 160 ns: 5 ns

For Widths ≥ 160 ns: 150 ns.

Trailing to leading edges.

Maximum Delay:

For Delays < 160 ns: Delay ≤ (trig, period)- 5 ns.
For Delays ≥ 160 ns: Delay ≤ (trig, period) - 150 ns.
(For Double Pulses, see also Minimum Pulse
Separation.)

SINGLE CYCLE

Depression of the ENTER or EXEC key will initiate a
single delay and width sequence.
