12
SPECIFICATIONS
Programming
GPIB IEEE-488
Remote interface with all functions and parameters
programmable and bus triggerable. Interface Functions:
SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP0, DC1, DT1,
C0.
RS-232 Remote interface with all functions and parameters
programmable in full or half-duplex to 1200 baud and bus
triggerable.
LOCAL Pushbutton manual entry with panel LCD display.
General
DIMENSIONS 12.75" W x 5.25" H x 16" D (324 mm x 133 mm x
406 mm).
Rack Mount: 19" W x 6.97" H x 16" D (483 mm x
177 mm x 406 mm).
WEIGHT 16 lbs net (7.3 kg): 23 lbs shipping (10.4 kg).
Rack Mount: 5 lbs net (2.3 kg): 10 lbs shipping
(4.5 kg).
POWER 115/230 V ± 10 %. 50/60 Hz. 80 W.
AMBIENT TEMPERATURE Operating Range: 0° - 50° C (32° -122° F).
Specifications apply: 10° - 40° C (50° - 104° F).
Module Characteristics
PERMANENT MEMORY A ROM in the module determines the instrument's
allowable operating conditions and display units.
STORE Ten complete instrument settings can be stored in the
module's nonvolatile RAM. The module may be removed
without loss of these settings.
