ARB 3232200 User Manual
Page 5
02-08-12
Page 5 of 23
3787827
6151021
2
BOLT M8 x 20mm
6151132
2
NUT FLANGE M8
4581044
2
WASHER FLAT M8
180302
6
CABLE TIES
USE
PART No QTY
DESCRIPTION
WASHER BOTTLE
SUPPORT TO IMPACT
ABSORBERS
3756801
2
WASHER BOTTLE SUPPORT BRACKET
6151301
4
CAGE NUT M8
6151021
4
BOLT M8 x 20mm HEX HEAD
4581044
4
WASHER FLAT M8
4581046
4
WASHER SPRING M8
6151300
2
CAGE NUT M6
6151213
2
BOLT M6 x 20mm BLACK ZINK
4581082
2
WASHER FLAT M6 x 20 BLACK ZINK
4581287
2
WASHER SPRING M6 BLACK ZINK
STONE TRAY & FAIRLEAD
COVER TO BULL BAR
6542109
1
STONE TRAY
3758045
1
FAIRLEAD COVER
6151357
4
BOLT M10 SEMS
6151304
4
CAGE NUT M10
6151300
4
CAGE NUT M6
6151213
6
BOLT M6 x 20mm BLACK ZINK
4581082
6
WASHER FLAT M6 x 20 BLACK ZINK
4581287
6
WASHER SPRING M6 BLACK ZINK
WASHER BOTTLE STONE
TRAYS TO BULL BAR
6542110L
1
WASHER BOTTLE TRAY
6542110R
1
WASHER BOTTLE TRAY
6151301
2
CAGE NUT M8
6151300
10
CAGE NUT M6
6151262
2
BOLT M8 x 20mm BLACK ZINK
4581045
2
WASHER FLAT M8 BLACK ZINK
4581047
2
WASHER SPRING M8 BLACK ZINK
6151213
10
BOLT M6 x 20mm BLACK ZINK
4581082
10
WASHER FLAT M6 x 20 BLACK ZINK
4581287
10
WASHER SPRING M6 BLACK ZINK
RETAINING FENDER
LINERS TO WASHER
BOTTLE TRAYS
6151300
4
CAGE NUT M6
6151213
4
BOLT M6 x 20mm BLACK ZINK
4581082
4
WASHER FLAT M6 x 20 BLACK ZINK
4581287
4
WASHER SPRING M6 BLACK ZINK
MISCELLANEOUS
180302
10
CABLE TIES
3162152
2
ARIAL PLUG
6191009
1
PLASTIC SIDE MOULDING
