ARB 3232200 User Manual
Page 4
02-08-12
Page 4 of 23
3787827
USE
PART no QTY
DESCRIPTION
IMPACT ABSORBER TO
CHASSIS
3758047L
1
CHASSIS MOUNT BRACKET ASSEMBLY
3758047R
1
CHASSIS MOUNT BRACKET ASSEMBLY
6151204
4
BOLT M10 x 35 x 1.5p HEX HEAD
6151321
4
NUT FLANGE M10 x 1.5
4581040
4
WASHER FLAT M10
4581048
4
WASHER SPRING M10
6151022
8
BOLT M8 x 25mm HEX HEAD
4581044
8
WASHER FLAT M8
4581046
8
WASHER SPRING M8
CR08
1
SPIRAL WRAP
BULL BAR TO IMPACT
ABSORBER
6151204
8
BOLT M10 x 35 x 1.5p HEX HEAD
6151321
8
NUT FLANGE M10 x 1.5
4581040
8
WASHER FLAT M10
4581048
8
WASHER SPRING M10
BUFFERS TO BULL BAR
3162470L
1
BUFFER 260 x 230 STANDARD
3162470R
1
BUFFER 260 x 230 STANDARD
6151128
12
NUT FLANGE M6
LICENCE PLATE TO BULL
BAR
6821116
2
NYLON PLUG
6151143
2
SCREW TEK 8-18 x 20mm
FOG LIGHTS, INDICATORS
AND SENSORS (IF FITTED)
TO BULL BAR
6151300
4
CAGE NUT M6
6821116
4
NYLON PLUG
3758046L
1
FOG LIGHT BRACKET
3758046R
1
FOG LIGHT BRACKET
3756778L
1
COVER MOUNT BRACKET
3756778R
1
COVER MOUNT BRACKET
3758092
2
BRACKET OUTER SENSOR MOUNT
3758093
2
BRACKET INNER SENSOR MOUNT
6821151L
1
INDICATOR COMBINATION LAMP
6821151L
1
INDICATOR COMBINATION LAMP
6821152
2
COMBINATION LAMP WIRING LOOM
180701
6
SCOTCH LOCK
6151309
6
CAPTIVE U-TYPE NUT
3162468
2
FOG LIGHT INSERT
6151317
8
SCREW 8-18 x 5/8 PAN HEAD
6151213
8
BOLT M6 x 20mm BLACK ZINK
4581082
8
WASHER FLAT M6 x 20 BLACK ZINK
4581287
4
WASHER SPRING M6 BLACK ZINK
6151128
4
NUT FLANGE M6
6151308
4
SCREW 8-AB X 1” PAN HEAD
6151460
4
SCREW SELF TAPPING
3787854
1
DRILLING TEMPLATE OUTER
3787855
1
DRILLING TEMPLATE INNER
6821198
1
INDICATOR LOOM KIT
WINCH TO BULL BAR
(SUPPLIED WITH FITTING
KIT 6171975 ONLY)
3756499
1
CONTROL BOX MOUNT
BLB850
3
WINCH LEAD 850mm BLACK
6151074
2
BOLT 3/8” x 1 ¾” HEX HEAD
6151073
2
BOLT 3/8” x 1 ½” HEX HEAD
4581040
4
WASHER FLAT M10
4581048
4
WASHER SPRING M10
